Researchers at the U.S. Department of Energy's (DOE) Argonne National Laboratory, in collaboration with Rice University and DOE's Lawrence Berkeley National Laboratory, have made important advances in understanding the mesoscale properties of a ferroelectric material under an electric field. This development holds potential for innovations in computer memory, lasers for scientific instruments, and sensors for ultraprecise measurements.
The ferroelectric material in question is an oxide composed of lead, magnesium, niobium, and titanium, known as a relaxor ferroelectric. It features tiny pairs of positive and negative charges, or dipoles, that form clusters called "polar nanodomains." Under an electric field, these dipoles align in the same direction, causing the material to change shape, or strain. Similarly, applying a strain can alter the dipole direction, generating an electric field.
"If you analyze a material at the nanoscale, you only learn about the average atomic structure within an ultrasmall region," said Yue Cao, an Argonne physicist. "But materials are not necessarily uniform and do not respond in the same way to an electric field in all parts. This is where the mesoscale can paint a more complete picture bridging the nano- to microscale."
A fully functional device based on a relaxor ferroelectric was created by professor Lane Martin's group at Rice University to test the material under operating conditions. Its main component is a thin film (55 nanometers) of the relaxor ferroelectric, placed between nanoscale layers serving as electrodes to apply a voltage and generate an electric field.
Using beamlines in sectors 26-ID and 33-ID of Argonne's Advanced Photon Source (APS), the Argonne team mapped the mesoscale structures within the relaxor. A specialized technique called coherent X-ray nanodiffraction, available through the Hard X-ray Nanoprobe (Beamline 26-ID) operated by the Center for Nanoscale Materials at Argonne and the APS, was crucial for this experiment. Both facilities are DOE Office of Science user facilities.
The results demonstrated that, under an electric field, the nanodomains self-assemble into mesoscale structures with dipoles aligning in a complex tile-like pattern. The team identified the strain locations along the borders of this pattern and the regions that responded more strongly to the electric field.
"These submicroscale structures represent a new form of nanodomain self-assembly not known previously," noted John Mitchell, an Argonne Distinguished Fellow. "Amazingly, we could trace their origin all the way back down to underlying nanoscale atomic motions; it's fantastic!"
"Our insights into the mesoscale structures provide a new approach to the design of smaller electromechanical devices that work in ways not thought possible," Martin said.
"The brighter and more coherent X-ray beams now possible with the recent APS upgrade will allow us to continue to improve our device," said Hao Zheng, the lead author of the research and a beamline scientist at the APS. "We can then assess whether the device has application for energy-efficient microelectronics, such as neuromorphic computing modeled on the human brain." Low-power microelectronics are essential for addressing the ever-growing power demands from electronic devices around the world, including cell phones, desktop computers, and supercomputers.
Research Report:Heterogeneous field response of hierarchical polar laminates in relaxor ferroelectrics
